Desktop Servo Control Tensile Strength Testing Machine Convenient Operation

Name: Desktop Servo Control Tensile Strength Testing Machine Convenient Operation
Brand: SKYLINE
Price: 1 USD

Quality Desktop Servo Control Tensile Strength Testing Machine Convenient Operation for sale

Place of Origin : CHINA

Brand Name : SKYLINE

Certification : Desktop Tensile Testing Machine

Model Number : SL-T801

MOQ : 1 UNIT

Packaging Details : standard exported package

Delivery Time : 10 days after getting payment

Payment Terms : TT , Western Union,paypal

Supply Ability : 8 pcs/ month

SKYLINE : Desktop Tensile Strength Tester

Maximum Load : 1KN high-precision sensors from U.S.A

Capacity choice : 200N, 500N, 1KN,200kg or less than can be self-selected

Units : Kg, lb, N

Resolution : 1 / 50000

Power Systems : Servo Motor

Contact Now

Desktop Servo Control Tensile Strength Testing Machine Convenient Operation

Product Information
Desktop Servo Tensile Strength Tester is a simple type machine, simple structure, convenient operation, It can be tested on the operated table, Using the servo control systems, load sensor is rising and falling to test the tension or compression through the motor rotation, transmission machinery and T-screws. This machine is simple to operate, especially suitable for controlling quality in production line, This series of machine is mainly applied to test the non-metallic and metallic materials which the load is less than 1KN.

Main functions
This machine can test all the material in tensile, compression, bending, shear, peel, tear, two-point extended (need add extensometer) and others for control products quality. Such as textile, rubber, plastics, synthetic leather, tape, adhesive, plastic film, composite materials, electronics, metals and other materials.

Technical parameters

Maximum Load	1KN high-precision sensors from U.S.A
Capacity choice	200N, 500N, 1KN,200kg or less than can be self-selected
Units	Kg, lb, N
Measured System	Load cell + HZ-2000
Accuracy of load measurement	the load cell + HZ-2000 screen ± 0.5% (full range of 5% -100%)
Resolution	1 / 50000
Power Systems	Servo Motor
Power	120W
Dimension	450 × 550 × 1400mm
Weight	70kg
Power	220V, 15A
